This fire-resistant glazed frame, provided with a RAL powder-coated finish, is designed with European standards compliance. This product's aesthetics and functionalities are adapted to your needs. It allows the integration of specific glazing and hardware. It can also be installed on a variety of support and be used in an extensive range of sectors.
Powder-coated finish available in standard RAL colours, with specialist finishes available upon request.
Anodised finishes available upon request.
EI90 Glazing
Single / double / triple glazing units
Glazing options: Acoustic, thermal insulation, screen printing...
Solid panel
Minimum (w x h)
On request
Maximum (w x h)
∞ x 4000 mm
| PERFORMANCES | |
| Fire classification |
E90 EW90 EI90 |
| REQUIREMENTS | |
| Supporting structure |
Rigid construction :
|
| Installation instructions | Rock wool filling and adapted fixings on the support |
AluTeq is a versatile range of glazed, fire-rated solutions incorporating aluminium profile systems for doors, windows and curtain walling. Offering a choice of designs and performance levels, AluTeq can be tailored to suit a wide range of project requirements.
