Wooden fire-resistant frame - EI60 - SlimTeq

To all Fixed Windows

A wooden frame, non-fire-rated, available in three different levels of finishes : varnished, patent or untreated. The frame offers a wide range of uses for a variety of purposes across an extensive range of sectors. You also have a considerable choice regarding the glazing and the models.

APPLICATION FIELDS

Models / configurations



  • Fixed frame
  • Fixed frame with intermediate transom

Finishes

  • Untreated wood (Meranti, Oak, Ash wood, Afrormosia...)
  • Varnished wood
  • Lacquered wood with visible grain (RAL coating available)
  • Lacquered wood with invisible grain (RAL coating available)

Infill

EI60 Glazing

Single glazing

Glazing options: Acoustic, thermal insulation, screen printing...



DIMENSIONS

Minimum (w x h)

On request



Maximum (w x h)

FRAME DIMENSIONS TOP LIGHT HEIGHT FRAME HEIGHT + TOP LIGHT
1830 x 3000 mm 720 mm  3500 mm



FEATURES

PERFORMANCES
Fire classification EI60



REQUIREMENTS
Supporting structure
  • Reinforced concrete (d ≥ 2200 Kg/m3, t ≥ 150 mm)
  • Solid concrete (d ≥ 1600 Kg/m3, t ≥ 150 mm)
  • Breeze blocks (d ≥ 1600 Kg/m3, t ≥ 150 mm)
  • Cellular concrete (d ≥ 500 Kg/m3, t ≥ 150 mm)
  • Fire-resistant pole
  • Light partition
  • Fixed glazed frame
Installations instructions Polyurethane foam or stripes with wooden struds and adapted fixings on the support



CERTIFICATIONS

SlimTeq

SlimTeq is a range of high-end architectural interior solutions incorporating a proprietary timber profile system and fire-rated performance. Combining natural aesthetics with technical excellence, it is available in a range of finishes including untreated, stained, and varnished, making it ideal for projects that require both design flexibility and fire protection.
