A fire-resistant, glazed, wooden door, available in three different level of finishes: varnished, patent or untreated. The door allows a wide range of uses for a variety of purposes across an extensive range of sectors. You also have a considerable choice regarding hardware and functions.

APPLICATION FIELDS

Models



  • Single door
  • Double door

Finishes

  • Untreated wood (Meranti, Oak, Ash wood, Afrormosia...)
  • Varnished wood
  • Lacquered wood with visible grain (RAL coating available)
  • Lacquered wood with invisible grain (RAL coating available

Infill

EI30 Glazing

Single glazing

Glazing options: Acoustic, thermal insulation, screen printing...



DIMENSIONS

Minimum (w x h)

On request



Maximum (w x h)

Single door Double door
1130 x 2950 mm 2 x 1130 x 2950 mm



FEATURES

Hardware

  • Traversing cylinder
  • 3-points lock
  • Electric door closer
  • Electric strike
  • Automatic door treshold



PERFORMANCES
Fire classification

EI30

EW30

E30



REQUIREMENTS
Supporting structure
  • Reinforced concrete (d ≥ 2200 Kg/m3, t ≥ 150 mm)
  • Solid concrete (d ≥ 1600 Kg/m3, t ≥ 150 mm)
  • Cellular concrete (d ≥ 500 Kg/m3, t ≥ 150 mm)
  • Light partition



CLASSIFICATIONS

SlimTeq

SlimTeq is a range of high-end architectural interior solutions incorporating a proprietary timber profile system and fire-rated performance. Combining natural aesthetics with technical excellence, it is available in a range of finishes including untreated, stained, and varnished, making it ideal for projects that require both design flexibility and fire protection.
