The glazed fire-resistant swing door, provided with a RAL powder-coated finish is designed with European standards compliance. This product's aesthetics and functionalities are adapted to your needs. The door allows the integration of specific glazing and hardware. It can also be installed on a variety of support and be used in an extensive range of sectors.
Powder-coated finish available in standard RAL colours, with specialist finishes available upon request.
E30 Glazing
Single / Double glazing
Glazing options: Acoustic, thermal insulation, opal, screen printing...
Solid panel
Minimum (w x h)
On request
Maximum (w x h)
| Single door free passage | Double door free passage | Panel | Max height light partition |
| 1328 x 2579 mm | 2313 x 2562 mm |
2.38 m² (glazed area > panel area) |
No limit x 4000 mm Top light: 700 mm |
| PERFORMANCES | |
| Fire classification |
E30 EW30 |
| REQUIREMENTS | |
| Supporting structure |
|
| Installation instructions | Rock wool filling and adapted fixings on the support |
| Door functions |
Standard function
Access control function
DAS mode 2 function
|
SteelTeq is a range of glazed and fire-rated interior solutions incorporating steel profiles, available in a wide range of aesthetic and performance options.
